Description
- The RXEF010 from TE Connectivity is a radial leaded PolySwitch resettable device. It provides engineers with more design flexibility. The higher voltage ratings allow this device to use in new applications and it is compatible with high volume electronics assembly.
RXEF010 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Voltage Rating (DC) | 60.0 V |
| Operating Voltage | 60 V |
| Time to Trip | 4 s |
| Flammability Rating | UL 94 V-0 |
| Power Dissipation | 0.38 W |
| Resistance | 7.5 Ω |
| Holding Current | 100 mA |
| Trip Current | 200 mA |
| Current Rating (Max) | 40 A |
| Holding Current (Max) | 100 mA |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Voltage Rating (Max) | 60 V |
| Voltage Rating | 60 VDC |
| Operating Voltage (Max) | 60 V |
| Show | |
| Size-Length | 11.6 mm |
| Size-Height | 12.7 mm |
| Lead Length | 7.6 mm |
| Cord Length | 7.6 m |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance Edition | 2014/06/16 |
| ECCN Code | EAR99 |
