Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 2 Pin |
Case/Package | T-1 |
Number of Positions | 2 Position |
Forward Voltage | 1.3 V |
Wavelength | 900 nm |
Viewing Angle | 20° |
Peak Wavelength | 900 nm |
Power Dissipation | 150 mW |
Rise Time | 5 ns |
Reverse Breakdown Voltage | 50 V |
Maximum Forward Voltage (Max) | 1.3 V |
Fall Time | 5 ns |
Fall Time (Max) | 5 ns |
Fall Time (Max) | 5 ns |
Operating Temperature (Max) | 100 ℃ |
Operating Temperature (Min) | -40 ℃ |
Power Dissipation (Max) | 150 mW |
Show | |
Size-Length | 5.9 mm |
Size-Width | 5.1 mm |
Size-Height | 9 mm |
Operating Temperature | -40℃ ~ 100℃ |
Product Lifecycle Status | Active |
Packaging | Bulk |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
ECCN Code | EAR99 |
