SN65HVS885PWP - TI
Manufacturer:
TI
ManyChip's Part#:
MC7190715
Category:
Interface IC, Interface Controller
Package:
HTSSOP-28
Datasheet:
Datasheet 3D Model
Description:
8input, wide 0-34V digital-input serializer with 5V Vcc for industrial digital inputs 28-HTSSOP -40℃ to 125℃
Stock Locations:
Availability:
5 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 3.33

Updated at 16/07/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The SN65HVS885PWP is an eight-channel Serializer for high-channel density digital input modules in industrial and building automation. Operating from a 5V supply the device accepts field input voltages of up to 34V. In combination with galvanic isolators the device completes the interface between the high voltage signals on the field-side and the low-voltage signals on the controller side. Inputs signals are current limited and then validated by internal debounce filters. With the addition of few external components, the input switching characteristic can be configured in accordance with IEC61131-2 for Type 1, 2 and 3 sensor switches. Upon the application of load and clock signals, input data is latched in parallel into the shift register and afterwards clocked out serially. Cascading of multiple devices is possible by connecting the serial output of the leading device with the serial input of the following device, enabling the design of high-channel count input modules.
Eight digital sensor inputs
Selectable debounce filters from 0 to 3ms
Output drivers for external status LEDs
Cascadable for more inputs in multiples of eight
SPI-compatible interface
Over-temperature indicator
Green product and no Sb/Br
Device has limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.

Show

SN65HVS885PWP Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	28 Pin
Case/Package	HTSSOP-28
Supply Voltage (DC)	4.50V (min)
Operating Voltage	4.50 V to 5.50 V
Number of Outputs	1 Output
Supply Current	5.20 mA
Number of Positions	28 Position
Input Current	0.2mA ~ 5.2mA
Power Dissipation	1100 W
Data Rate	1.00 Mbps
Number of Inputs	8 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	1100 mW
Supply Voltage	4.5V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
	Show
Size-Length	9.8 mm
Size-Width	4.5 mm
Size-Height	1.05 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
