Description

The STN1HNK60 is a 600V N-channel SuperMESH™ MOSFET with extreme optimization of well established strip-based PowerMESH™ layout. In addition to pushing on-resistance significantly down, special care is taken to ensure a very good dv/dt capability for the most demanding applications. Improved gate charge and lower power dissipation to meet today"s challenging efficiency requirements.
Extremely high dv/dt capability
ESD improved capability
100% Avalanche tested
New high voltage benchmark
Gate charge minimized
ESD sensitive device, take proper precaution while handling the device.

Show

STN1HNK60 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	TO-261-4
Voltage Rating (DC)	600 V
Current Rating	400 mA
Number of Channels	1 Channel
Number of Positions	3 Position
Drain to Source Resistance (on) (Rds)	8 Ω
Polarity	N-Channel
Power Dissipation	3.3 W
Threshold Voltage	3 V
Drain to Source Voltage (Vds)	600 V
Breakdown Voltage (Drain to Source)	600 V
Continuous Drain Current (Ids)	500 mA
Rise Time	5 ns
Input Capacitance (Ciss)	156pF @25V(Vds)
Input Power (Max)	3.3 W
Fall Time	25 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	3.3W (Tc)
	Show
Size-Length	6.5 mm
Size-Width	3.5 mm
Size-Height	1.8 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
