Description

The STN3N45K3 is a 450V N-channel Zener-protected SuperMESH™ Power MOSFET with a new optimized vertical structure. The MOSFET boasts an extremely low on resistance, superior dynamic performance and high avalanche capability, rendering it suitable for the most demanding applications. Improved gate charge and lower power dissipation to meet today"s challenging efficiency requirements.
Extremely high dv/dt capability
100% Avalanche tested
Gate charge minimized
Very low intrinsic capacitance
Improved diode reverse recovery characteristics
Zener-protected

Show

STN3N45K3 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	4 Pin
Case/Package	TO-261-4
Number of Channels	1 Channel
Number of Positions	4 Position
Drain to Source Resistance (on) (Rds)	3.2 Ω
Polarity	N-Channel
Power Dissipation	2 W
Threshold Voltage	3.75 V
Drain to Source Voltage (Vds)	450 V
Input Capacitance (Ciss)	150pF @25V(Vds)
Input Power (Max)	2 W
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	3W (Ta)
	Show
Size-Length	6.7 mm
Size-Width	3.7 mm
Size-Height	1.8 mm
Operating Temperature	150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
