Description

The STPS5L60S is a power Schottky Rectifier Diode for switch mode power supplies and high frequency inverters. This device is intended for use in low voltage output for small battery chargers and consumer SMPS such as DVD and set-top-box.
Low Thermal Resistance
Negligible Switching Losses
Low Forward Voltage Drop for Higher Efficiency
Avalanche Capability Specified

Show

STPS5L60S Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package	DO-214AB
Number of Positions	2 Position
Forward Voltage	520mV @5A
Thermal Resistance	15℃/W (RθJL)
Forward Current	5 A
Max Forward Surge Current (Ifsm)	150 A
Maximum Forward Voltage (Max)	520 mV
Forward Current (Max)	5 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-65 ℃
Junction Temperature	150℃ (Max)
	Show
Size-Length	7.15 mm
Size-Width	6.25 mm
Size-Height	2.45 mm
Operating Temperature	-65℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
ECCN Code	EAR99
