TLE6220GP - Infineon
Manufacturer:
Infineon
ManyChip's Part#:
MC7901959
Category:
FET Driver
Package:
PG-DSO-20
Datasheet:
Datasheet 3D Model
Description:
INFINEON TLE6220GP Power Load Switch, Low Side, Active High, Active Low, 4Outputs, 5.5V, 4.5A, SOIC-20
Stock Locations:
Availability:
761 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 6.22

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The TLE6220GP is a quad channel low-side Switch in Smart Power Technology (SPT) with a Serial Peripheral Interface (SPI) and four open drain DMOS output stages. The TLE 6220 GP is protected by embedded protection functions. The output stages can be controlled direct in parallel for PWM applications (injector coils) or through serial control via the SPI. Therefore the TLE 6220 GP is particularly suitable for engine management and powertrain systems.
Short-circuit protection
Overtemperature protection
Overvoltage protection
8-bit serial data input and diagnostic output (SPI protocol)
Direct parallel control of four
Channels for PWM applications
Cascadable with other quad switches
Low quiescent current
µC compatible input
Green product
AEC qualified

Show

TLE6220GP Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	PG-DSO-20
Number of Outputs	4 Output
Input Voltage (DC)	5.50 V
Output Voltage	60 V
Output Current	1 A
Number of Channels	4 Channel
Number of Positions	20 Position
Output Current (Max)	3 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	4.5V ~ 5.5V
Input Voltage	5.5 V
	Show
Size-Length	15.9 mm
Size-Width	11 mm
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
