Image is for your reference only,please check specifications for details
- TPD1E04U04DPYT - TI
-
Manufacturer:TI
-
ManyChip's Part#:MC16563333
-
Category:Diode
-
Package:XDFN-2
-
Datasheet:Datasheet 3D Model
-
Description:1Channel ESD Protection Diode With Low Dynamic Resistance for HDMI 2.0 and USB 3.0 2-X1SON -40℃ to 125℃
-
Stock Locations:
-
Availability:215 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0.83
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- 8.9V Clamp 2.5A (8/20µs) Ipp Tvs Diode Surface Mount 2-X1SON (1x.60)
TPD1E04U04DPYT Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 2 Pin |
| Case/Package | XDFN-2 |
| Capacitance | 0.65 pF |
| Clamping Voltage | 8.9 V |
| Max Breakdown Voltage | 7.5 V |
| Peak Pulse Power | 19 W |
| Min Breakdown Voltage | 4.5 V |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Show | |
| Size-Height | 0.4 mm |
| Operating Temperature | -40℃ ~ 125℃ (TA) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
