- TPS61093DSKR - TI
-
Manufacturer:TI
-
ManyChip's Part#:MC17291165
-
Category:DC to DC Converter
-
Package:WSON-10
-
Datasheet:Datasheet 3D Model
-
Description:Low Input, 20V/1.1A Step-Up DC-DC Converter with Integrated Power Diode and Input/Output Isolation 10-SON -40℃ to 85℃
-
Stock Locations:
-
Availability:461 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 5.06
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Adjust the voltage level of your devices with this step up TPS61093DSKR DC to DC converter from Texas Instruments. This converter"s single output can produce a current up to 0.3 A. The best way to provide power to your application is by using this, which needs a voltage of at least 1.6 V and no higher than 6 V. With an adjustable output that has a voltage of 1.6 to 17 V, this is power management at its best. This converter is 88 % efficient. This part offers a switching frequency of 1000 to 1400 kHz in order to work properly. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This converter has an operating temperature range of -40 °C to 85 °C. The converter is ideal for operating at an isolation of Isolated.
TPS61093DSKR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 10 Pin |
| Case/Package | WSON-10 |
| Number of Outputs | 1 Output |
| Output Voltage | 1.6V ~ 17V |
| Output Current | 0.3 A |
| Number of Positions | 10 Position |
| Quiescent Current | 900 µA |
| Number of Regulated Outputs | 1 Output |
| Switching Frequency | 1.2 MHz |
| Topology | Boost |
| Input Voltage (Max) | 6 V |
| Input Voltage (Min) | 1.6 V |
| Output Voltage (Max) | 17 V |
| Output Voltage (Min) | 1.6 V |
| Output Current (Max) | 0.3 A |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Input Voltage | 6 V |
| Show | |
| Operating Temperature | -40℃ ~ 85℃ (TA) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| HK STC License | NLR |
