- VIPER06LSTR - ST Microelectronics
-
Manufacturer:ST Microelectronics
-
ManyChip's Part#:MC11738819
-
Category:AC to DC Converter, AC/DC Power Module
-
Package:SOP-10
-
Datasheet:Datasheet 3D Model
-
Description:AC-DC Converter IC, VIPerPlus Family, Flyback, 85VAC - 265VAC, 8W, SSO-10
-
Stock Locations:
-
Availability:274 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 2.5
Updated at 31/10/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The VIPER06LSTR is a VIPer™ plus fixed-frequency energy-saving Off-line Converter with an 800V avalanche rugged power section, a PWM controller, a user-defined over-current limit, open-loop failure protection and hysteretic thermal protection. The 4W high voltage converter features soft start-up and safe auto-restart after any fault condition. The device is able to power itself directly from the rectified mains and eliminating the need for an auxiliary bias winding. Burst mode operation and the device have very low power consumption both help to meet the standards set by energy-saving regulations.
- PWM operation with frequency jittering for low EMI
- No need for an auxiliary winding in low-power applications
- Limiting current with adjustable set point
- On-board soft-start
- Safe auto-restart after a fault condition
- Hysteretic thermal shutdown
VIPER06LSTR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 10 Pin |
| Case/Package | SOP-10 |
| Power Rating | 8 W |
| Output Voltage | 800 V |
| Breakdown Voltage | 800 V |
| Number of Positions | 10 Position |
| Switching Frequency | 60 kHz |
| Duty Cycle | 70 % |
| Input Voltage (Max) | 23.5 V |
| Input Voltage (Min) | 11.5 V |
| Input Voltage (AC Max) | 265 v |
| Input Voltage (AC Min) | 85 v |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage (Max) | 23.5 V |
| Supply Voltage (Min) | 11.5 V |
| Input Voltage | 11.5V ~ 23.5V |
| Show | |
| Size-Length | 5 mm |
| Size-Width | 4 mm |
| Size-Height | 1.25 mm |
| Operating Temperature | -40℃ ~ 150℃ |
| Product Lifecycle Status | Active |
| Packaging | Cut Tape (CT) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| ECCN Code | EAR99 |
| HK STC License | NLR |
