Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Case/Package | - |
Pin Pitch | 5.08 mm |
Number of Contacts | 2 Contact |
Wire Gauge | 12AWG ~ 30AWG |
Contact Plating | Tin |
Current Rating | 12 A |
Number of Rows | 1 Row |
Number of Circuits | 2 Circuit |
Flammability Rating | UL 94 V-0 |
Number of Positions | 2 Position |
Mounting Angle | 90.0 ° |
Current Rating (Max) | 12 A |
Voltage Rating (Max) | 320 V |
Voltage Rating | 250 V |
Operating Voltage (Max) | 320 V |
Show | |
Size-Length | 11.7 mm |
Size-Width | 18.2 mm |
Size-Height | 15 mm |
Housing Color | Green |
Color | Green |
Material | Nylon |
Weight | 0.0038 KG |
Housing Material | Nylon |
Product Lifecycle Status | Active |
Packaging | Bulk |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
HTS Code | 8536694040 |
ECCN Code | EAR99 |
