Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 2 Pin |
Case/Package | DO-41 |
Voltage Rating (DC) | 400 V |
Current Rating | 1 A |
Capacitance | 15 pF |
Output Current | 1 A |
Number of Positions | 2 Position |
Forward Voltage | 1.1 V |
Polarity | Standard |
Power Dissipation | 3 W |
Thermal Resistance | 50℃/W (RθJA) |
Forward Current | 1 A |
Max Forward Surge Current (Ifsm) | 30 A |
Maximum Forward Voltage (Max) | 1.1 V |
Forward Current (Max) | 1 A |
Operating Temperature (Max) | 175 ℃ |
Operating Temperature (Min) | -55 ℃ |
Junction Temperature (Max) | 175 ℃ |
Show | |
Size-Length | 5.2 mm |
Size-Width | 2.72 mm |
Size-Height | 5.2 mm |
Weight | 0.004535924 kg |
Operating Temperature | -55℃ ~ 175℃ |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/06/15 |
ECCN Code | EAR99 |
