22041031 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Case/Package	Through Hole
Pin Pitch	2.50 mm
Number of Contacts	3 Contact
Gender	Male
Contact Plating	Tin
Voltage Rating (DC)	250 V
Voltage Rating (AC)	250 V
Current Rating	3.00 A
Insulation Resistance	1.00 GΩ
Number of Rows	01 Row
Glow Wire Compliant	Non-Compliant
Halogen Free Status	Low Halogen
Orientation	Vertical
Number of Circuits	3 Circuit
Flammability Rating	UL 94 V-0
Number of Positions	3 Position
Contact Resistance	20.0 mΩ
Current Rating (Max)	3A/触头
Maximum Contact Resistance (Max)	20 mΩ
	Show
Size-Length	7.00 mm
Size-Width	5.80 mm
Size-Height	11.7 mm
Housing Color	Natural
Color	Natural
Contact Material	Brass
Housing Material	Nylon
Product Lifecycle Status	Active
Packaging	Bag
RoHS	RoHS-conform
Lead-Free Status	Lead Free
ECCN Code	EAR99
