Image is for your reference only,please check specifications for details

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

**dc/dc, dc/ac & ac/dc Opto-Couplers**
These DIN rail mount opto-couplers provide an ideal means of interfacing on/off signals to, or from, equipment, whilst providing electrical isolation between their own inputs and outputs. In other words, these may be used to protect equipment by electrically isolating its inputs, outputs, or both. The dc/ac and ac/dc versions also provide a means of interfacing (whilst isolating) ac and dc control voltages.

Show

2964283 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Screw, DIN Rail
Number of Pins	5 Pin
Case/Package	Module
Operating Voltage	30.0V (max)
Output Current	50 mA
Load Current	50 mA
Input Current	6 mA
Power Dissipation	3 mW
Isolation Voltage	2.5 kV
Output Voltage (Max)	30 V
Output Current (Max)	0.05 A
Input Current (Min)	6 mA
Maximum Forward Voltage (Max)	24 V
Operating Temperature (Max)	60 ℃
Operating Temperature (Min)	-20 ℃
Power Dissipation (Max)	3 mW
Operating Voltage (Min)	4 V
Operating Voltage (Max)	30 VDC
Input Voltage	24 VDC
	Show
Size-Length	80 mm
Size-Width	6.2 mm
Size-Height	80 mm
Operating Temperature	-20℃ ~ 60℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
HTS Code	8536410060
ECCN Code	EAR99
