AD5432YRMZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC4194230
Category:
Digital to Analog, DAC IC
Package:
MSOP-10
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD5432YRMZ Digital to Analog Converter, 10Bit, 2.5MSPS, Serial, 3V to 5.5V, SOP, 10Pins
Stock Locations:
Availability:
246 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 4.7

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD5432YRMZ is a CMOS 10-bit current output Digital-to-analog Converter (DAC) operates from a 2.5 to 5.5V power supply, making it suitable for many applications. This DAC uses a double buffered, 3-wire serial interface that is compatible with SPI, QSPI™, MICROWIRE and most DSP interface standards. Data read-back allows the user to read the contents of the DAC register via the SDO pin. On power-up, the internal shift register and latches are filled with 0s and the DAC outputs are at zero scale. As a result of manufacturing on a CMOS submicron process, the part offers excellent 4-quadrant multiplication characteristics with large signal multiplying bandwidths of 10MHz. The applied external reference input voltage VREF determines the full-scale output current. An integrated feedback resistor, RFB, provides temperature tracking and full-scale voltage output when combined with an external current to voltage precision amplifier.
Low glitch energy <2nV-s
Pin-compatible 10-bit current output DAC
Guaranteed monotonic
Power-on reset with brownout detection
Daisy-chain mode
0.4µA Typical power consumption

Show

AD5432YRMZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	10 Pin
Case/Package	MSOP-10
Number of Outputs	1 Output
Number of Channels	1 Channel
Number of Positions	10 Position
Number of Bits	10 Bit
Power Dissipation	27.5 µW
Sample Rate	2.5 Msps
Resolution (Bits)	10.0 Bit
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Number of DACs	1 DAC
Supply Voltage	3V ~ 5.5V
	Show
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.85 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
