Description
- High-Power Switching Applications
- Hammer Drive, Pulse Motor Drive Applications
- • High DC current gain: hFE= 2000 (min) (VCE= 3 V, IC= 3 A)
- • Low saturation voltage: VCE (sat)= 1.5 V (max) (IC= 3 A)
2SD1415A Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Number of Pins | 3 Pin |
| Case/Package | TO-220 |
| Polarity | NPN |
| Breakdown Voltage (Collector to Emitter) | 100 V |
| Continuous Collector Current | 7A |
| Show | |
| Product Lifecycle Status | Obsolete |
| RoHS | RoHS Compliant |
