Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | DIN Rail |
Number of Contacts | 2 Contact |
Wire Gauge | 16mm² ~ 70mm² |
Current Rating | 150 A |
Flammability Rating | UL 94 V-0 |
Number of Positions | 2 Position |
Current Rating (Max) | 150 A |
Load Current (Max) | 150 A |
Voltage Rating (Max) | 1000 V |
Voltage Rating | 1 kV |
Operating Voltage (Max) | 1000 V |
Show | |
Size-Length | 70.5 mm |
Size-Width | 20 mm |
Size-Height | 75.8 mm |
Housing Color | Blue |
Color | Blue |
Product Lifecycle Status | Active |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
HTS Code | 8536904000 |
ECCN Code | EAR99 |
