- NCP1030DMR2G - ON Semiconductor
-
Manufacturer:ON Semiconductor
-
ManyChip's Part#:MC14557640
-
Category:AC to DC Converter, AC/DC Power Module
-
Package:Micro-8
-
Datasheet:Datasheet 3D Model
-
Description:NCP Series 4mA 800kHz Low Power PWM Controller On-Chip Power Switch - Micro8
-
Stock Locations:
-
Availability:264 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 4.12
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Low Power PWM Controller with On−Chip Power Switch and Startup Circuits for 48V Telecom Systems
- The NCP1030 and NCP1031 are a family of miniature high−voltage monolithic switching regulators with on−chip Power Switch and Startup Circuits. The NCP103x family incorporates in a single IC all the active power, control logic and protection circuitry required to implement, with minimal external components, several switching regulator applications, such as a secondary side bias supply or a low power dc−dc converter.
- This controller family is ideally suited for 48 V telecom, 42 V automotive and 12 V input applications. The NCP103x can be configured in any single−ended topology such as forward or flyback. The NCP1030 is targeted for applications requiring up to 3 W, and the NCP1031 is targeted for applications requiring up to 6 W.
NCP1030DMR2G Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | Micro-8 |
| Frequency | 800 kHz |
| Power Rating | 3 W |
| Halogen Free Status | Halogen Free |
| Number of Outputs | 2 Output |
| Output Voltage | 8.6 V |
| Output Current | 500 mA |
| Breakdown Voltage | 200 V |
| Number of Positions | 8 Position |
| Power Dissipation | 582 mW |
| Switching Frequency | 300 kHz |
| Topology | Flyback, Step-Up, Step-Down |
| Thermal Resistance | 172 ℃/W |
| Duty Cycle | 75 % |
| Input Voltage (Max) | 16 V |
| Input Voltage (Min) | 8 V |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage | 8V ~ 16V |
| Supply Voltage (Max) | 200 V |
| Supply Voltage (Min) | 8 V |
| Input Voltage | 7.6V ~ 16V |
| Show | |
| Operating Temperature | -40℃ ~ 150℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
