74HC240D - NXP
Manufacturer:
NXP
ManyChip's Part#:
MC74497503
Category:
Logic Control, Logic Gate IC
Package:
SOIC
Datasheet:
Datasheet 3D Model
Description:
IC HC/UH SERIES, DUAL 4Bit DRIVER, INVERTED OUTPUT, PDSO20, 7.5MM, PLASTIC, MS-013, SOT163-1, SOP-20, Bus Driver/Transceiver
Stock Locations:
Availability:
436 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.85

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The 74HC240D is a 8-bit inverting Buffer/Line Driver with inverting 3-state outputs. The device can be used as two 4-bit buffers or one 8-bit buffer. The device features two output enables (1OE and 2OE), each controlling four of the 3-state outputs. A HIGH on nOE causes the outputs to assume a high-impedance OFF-state. Inputs include clamp diodes. This enables the use of current limiting resistors to interface inputs to voltages in excess of VCC.
Input CMOS level
Complies with JEDEC standard JESD7A

Show

74HC240D Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	SOIC
Supply Voltage (DC)	2.00V (min)
Number of Positions	20 Position
Number of Bits	8 Bit
Number of Gates	8 Gate
Number of Inputs	1 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	500 mW
Supply Voltage	5 V
Supply Voltage (Max)	6 V
Supply Voltage (Min)	2 V
	Show
Size-Length	13 mm
Size-Width	7.6 mm
Size-Height	2.45 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Unknown
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
HK STC License	NLR
