76SB08T - Grayhill
Manufacturer:
Grayhill
ManyChip's Part#:
MC13923357
Category:
DIP Switch, SIP Switch
Package:
DIP
Datasheet:
Datasheet 3D Model
Description:
GRAYHILL 76SB08T DIP / SIP Switch, Raised Rocker, 8Circuits, SPST, Through Hole, 76 Series, DIP Unsealed, 30VDC
Stock Locations:
Availability:
228 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.81

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The 76SB08T is a single-pole single-throw thru-hole DIP Switch with raised rocker actuator style, 8 circuits, 8 positions, 2.54mm pitch spacing and DIP unsealed type. Minimum at 100VDC between adjacent closed contacts and also across open switch contacts insulation resistance. Minimum voltage (AC, RMS) measured between adjacent closed contacts and also across open switch contacts dielectric strength.
Operations per switch position mechanical life
1MHz Switch capacitance
Thermoplastic non-conductive parts
UL94V-0 Flammability rating
Epoxy potting
Polyimide film tape seal
Tape seal integrity

Show

76SB08T Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Case/Package	DIP
Pin Pitch	2.54 mm
Voltage Rating (DC)	30 V
Actuator Type	Rocker
Current Rating	150 mA
Insulation Resistance	5.00 GΩ
Capacitance	5.00 pF
Orientation	Vertical
Contacts Type	SPST
Number of Circuits	8 Circuit
Number of Positions	8 Position
Contact Resistance	30.0 mΩ
Contact Current Rating	150mA @24VDC
Current Rating (Max)	0.15A @30VDC
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Voltage Rating	30 VDC
Voltage Rating (DC Max)	30 V
	Show
Size-Length	22.4 mm
Size-Width	9.65 mm
Size-Height	8 mm
Lead Length	3.96 mm
Contact Material	Copper Alloy
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2016/06/20
HTS Code	8536509065
ECCN Code	EAR99
