AD623ARMZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC217991
Category:
Instrumentation Amplifier IC
Package:
MSOP-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD623ARMZ Instrument Amplifier, 1 Amplifier, 500μV, 0.3V/µs, 800kHz, 2.7V to 12V, ± 2.5V to ± 6V, MSOP
Stock Locations:
Availability:
4,232 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 2.68

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD623ARMZ is a Single-Supply Rail-to-rail Instrumentation Amplifier that delivers rail-to-rail output swing on a 3V to 12V supply. The AD623 offers superior user flexibility by allowing single gain set resistor programming and by conforming to the 8-lead industry standard pinout configuration. With no external resistor, it is configured for unity gain (G = 1) and with an external resistor, it can be programmed for gains up to 1000. The AD623 holds errors to a minimum by providing superior AC CMRR that increases with increasing gain. Line noise as well as line harmonics are rejected because the CMRR remains constant up to 200Hz. The amplifier has a wide input common mode range and can amplify signals that have a common mode voltage 150mV below ground. Although the design of AD623 was optimized to operate from a single supply, it still provides superior performance when operated from a dual voltage supply (±2.5V to ±6.0V).
Easy to use
Higher performance than discrete design
Single-supply and dual-supply operation
Gain set with one external resistor
High accuracy DC performance
0.10% Gain accuracy (G = 1)
0.35% Gain accuracy (G > 1)
800kHz Bandwidth (G = 1)
20µs Settling time to 0.01% (G = 10)
ESD sensitive device, take proper precaution while handling the device.

Show

AD623ARMZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	MSOP-8
Supply Current	375 µA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Power Dissipation	0.65 W
Common Mode Rejection Ratio	110 dB
Bandwidth	800 kHz
Slew Rate	300 mV/μs
Gain Bandwidth Product	800 kHz
Input Offset Voltage	200 µV
Input Bias Current	17 nA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	800 kHz
Gain Bandwidth	70 dB
Power Dissipation (Max)	650 mW
Minimum CMRR Range	70 dB
Supply Voltage (Max)	10V ~ 15V
Supply Voltage (Min)	2.5 V
	Show
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.85 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
