AD7191BRUZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC719458
Category:
Analog to Digital, ADC IC
Package:
TSSOP-24
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD7191BRUZ Analog to Digital Converter, 24Bit, 120 SPS, Single, 3V, 5.25V, TSSOP
Stock Locations:
Availability:
223 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 55.49

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD7191BRUZ is a pin-programmable ultralow noise, 24-bit, sigma-delta Analog-to-digital Converter (ADC) for bridge sensors. The on-chip low noise gain stage means that signals of small amplitude can be interfaced directly to the ADC. It contains two differential analog inputs. The part also includes a temperature sensor that can be used for temperature compensation. For ease-of-use, all the features of the AD7191 are controlled by dedicated pins.
Pin-programmable output rate
Pin-programmable PGA
Pin-programmable power-down and reset
Internal or external clock
Bridge power-down switch
Specified drift over time
Simultaneous 50 Hz/60Hz rejection
Internal temperature sensor

Show

AD7191BRUZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	24 Pin
Case/Package	TSSOP-24
Supply Voltage (DC)	3.00V (min)
Supply Current	4.00 mA
Number of Positions	24 Position
Number of Bits	24 Bit
Power Dissipation	22.5 W
Sample Rate	120 SPS
Resolution (Bits)	24.0 Bit
Number of ADCs	1 ADC
Number of Inputs	2 Input
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	22.5 mW
Number of Input Channels	2 Channel
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	3 V
	Show
Size-Length	7.9 mm
Size-Width	4.5 mm
Size-Height	1.05 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2016/06/20
ECCN Code	EAR99
