AD7400AYRWZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC1604046
Category:
Analog to Digital, ADC IC
Package:
SOIC-16
Datasheet:
Datasheet 3D Model
Description:
Analogue to Digital Converter, Sigma Delta, 16Bit, 10MSPS, Single, 4.5V, 5.5V, SOIC
Stock Locations:
Availability:
235 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 4.45

Updated at 31/10/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD7400AYRWZ is an Isolated Sigma-Delta Modulator that converts an analog input signal into a high speed, 1-bit data stream with on-chip digital isolation based on Analog Devices, Inc, iCoupler® technology. The analog input is sampled continuously by the analog modulator, eliminating the need for external sample-and-hold circuitry. The input information is contained in the output stream as a density of ones with a data rate of 10MHz. The original information can be reconstructed with an appropriate digital filter. High speed CMOS, combined with monolithic air core transformer technology, means the on-chip isolation provides outstanding performance characteristics superior to alternatives such as optocoupler devices.
Serial interface is digitally isolated
Second-order modulator
Onboard digital isolator
Onboard reference

Show

AD7400AYRWZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Supply Voltage (DC)	4.50V (min)
Supply Current	11 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	16 Position
Number of Bits	16 Bit
Power Dissipation	95 mW
Sample Rate	10 Msps
Resolution (Bits)	16.0 Bit
Input Capacitance	10.0 pF
Number of ADCs	1 ADC
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	95 mW
Number of Input Channels	1 Channel
Supply Voltage	4.5V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
	Show
Size-Length	10.5 mm
Size-Width	7.6 mm
Size-Height	2.35 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2014/06/16
