AD7607BSTZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC674396
Category:
Analog to Digital, ADC IC
Package:
LQFP-64
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD7607BSTZ Analog to Digital Converter, 14Bit, 200KSPS, Single, 4.75V, 5.25V, LQFP
Stock Locations:
Availability:
63 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 16.24

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD7607BSTZ is a 8-channel Data Acquisition System with 14-bit bipolar input simultaneous sampling ADC. The part contains analog input clamp protection, a second-order anti-aliasing filter, a track-and-hold amplifier, a 14-bit charge redistribution, successive approximation analog-to-digital converter, a flexible digital filter, a 2.5V reference and reference buffer and high speed serial and parallel interfaces. It operates from a single 5V supply and can accommodate ±10 and ±5V true bipolar input signals while sampling at throughput rates of up to 200kSPS for all channels. The input clamp protection circuitry can tolerate voltages of up to ±16.5V. It has 1MR analog input impedance, regardless of sampling frequency. The single supply operation, on-chip filtering and high input impedance eliminate the need for driver op amps and external bipolar supplies. The anti-aliasing filter has a 3dB cutoff frequency of 22kHz and provides 40dB anti-alias rejection when sampling at 200kSPS.
8 Simultaneously sampled inputs
Fully integrated data acquisition solution
Analog input clamp protection
Input buffer with 1MR analog input impedance
Second-order antialiasing analog filter
On-chip accurate reference and reference buffer
Flexible parallel/serial interface SPI/QSPI™/MICROWIRE™/DSP compatible
Pin-compatible solutions from 14 to 18-bit

Show

AD7607BSTZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	64 Pin
Case/Package	LQFP-64
Supply Voltage (DC)	4.75V (min)
Number of Circuits	1 Circuit
Number of Channels	8 Channel
Number of Positions	64 Position
Number of Bits	14 Bit
Power Dissipation	100 mW
Sample Rate	200 ksps
Power Consumption	100 mW
Resolution (Bits)	14.0 Bit
Input Capacitance	20.0 pF
Input Impedance	1.00 MΩ
Number of ADCs	1 ADC
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	142 mW
Number of Input Channels	8 Channel
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	4.75 V
	Show
Size-Length	10.2 mm
Size-Width	10.2 mm
Size-Height	1.45 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2017/07/07
