AD8253ARMZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC708200
Category:
Instrumentation Amplifier IC
Package:
MSOP-10
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD8253ARMZ Instrument Amplifier, 3, 150V, 20V/ s, 10MHz, 5V to 15V, MSOP
Stock Locations:
Availability:
256 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 15.33

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD8253ARMZ is an Instrumentation Amplifier with digitally programmable gains that has gigaohm (GR) input impedance, low output noise and low distortion, making it suitable for interfacing with sensors and driving high sample rate analogue-to-digital converters (ADCs). In addition to its wide input common voltage range, it boasts a high common-mode rejection of 100dB at G=1000 from DC to 20kHz. The combination of precision DC performance coupled with high speed capabilities makes this an excellent candidate for data acquisition. Furthermore, this monolithic solution simplifies design and manufacturing and boosts performance of instrumentation by maintaining a tight match of internal resistors and amplifiers.
Digital or pin-programmable gain setting
±5 to ±15V Wide supply
Excellent DC performance
100dB Minimum high CMRR
10ppm/°C Maximum low gain drift
1.2µV/°C Maximum low offset drift
Excellent AC performance
780ns to 0.001% Maximum fast settling time
