IRLZ14 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220
Voltage Rating (DC)	60.0 V
Current Rating	10.0 A
Polarity	N-CH
Drain to Source Voltage (Vds)	60.0 V
Breakdown Voltage (Drain to Source)	60.0V (min)
Continuous Drain Current (Ids)	10.0 A
Rise Time	110 ns
Input Capacitance (Ciss)	400pF @25V(Vds)
Fall Time	26 ns
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	43000 mW
	Show
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
