AD8417BRMZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC677926
Category:
Amplifier, Buffer IC
Package:
MSOP-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD8417BRMZ Current Sense Amplifier, Bidirectional, 1 Amplifier, 130μA, MSOP, 8Pins, -40℃, 125℃
Stock Locations:
Availability:
3 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 7.63

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD8417BRMZ is a high voltage high resolution Current Shunt Amplifier features an initial gain of 60V/V, with a maximum ±0.3% gain error over the entire temperature range. The buffered output voltage directly interfaces with any typical converter. The AD8417 offers excellent input common-mode rejection from -2 to +70V. The AD8417 offers breakthrough performance throughout the -40 to +150°C temperature range. It features a zero drift core, which leads to a typical offset drift of 0.1µV/°C throughout the operating temperature range and the common-mode voltage range. The AD8417 is qualified for automotive applications. The device includes EMI filters and patented circuitry to enable output accuracy with pulse-width modulation (PWM) type input common-mode voltages. The typical input offset voltage is ±200µV.
Typical 0.1µV/°C offset drift
Maximum ±400µV voltage offset over full temperature range
Electromagnetic interference (EMI) filters included
Bidirectional operation
Indefinite output short-circuit duration
0.3V Reverse supply voltage
±2000V ESD human body model (HBM)

Show

AD8417BRMZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	MSOP-8
Supply Voltage (DC)	2.70V (min)
Supply Current	4.1 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	100 dB
Input Capacitance	2.00 pF
Bandwidth	250 kHz
Input Impedance	200 kΩ
Input Offset Voltage	200 µV
Input Bias Current	130 µA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	250 kHz
Gain Bandwidth	86 dB
Minimum CMRR Range	86 dB
Supply Voltage	2.7V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.7 V
	Show
Size-Length	3.2 mm
Size-Width	3.2 mm
Size-Height	0.95 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
Mil-Spec	Yes
REACH SVHC Compliance Edition	2015/12/17
