Image is for your reference only,please check specifications for details
- AD8417WHRMZ - ADI
-
Manufacturer:ADI
-
ManyChip's Part#:MC1994529
-
Category:Amplifier, Buffer IC
-
Package:MSOP-8
-
Datasheet:Datasheet 3D Model
-
Description:SP Amp Current Sense Amp Single ±2.75V/5.5V Automotive 8Pin MSOP Tube
-
Stock Locations:
-
Availability:257 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 2.25
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Product Details
- The AD8417 is a high voltage, high resolution current shunt amplifier. It features an initial gain of 60 V/V, with a maximum ±0.3% gain error over the entire temperature range. The buffered output voltage directly interfaces with any typical converter. The AD8417 offers excellent input common-mode rejection from −2 V to +70 V. The AD8417 performs bidirectional current measurements across a shunt resistor in a variety of automotive and industrial applications, including motor control, power management, and solenoid control.
- The AD8417 offers breakthrough performance throughout the −40°C to +150°C temperature range. It features a zero drift core, which leads to a typical offset drift of 0.1 μV/°C throughout the operating temperature range and the common-mode voltage range. The AD8417 is qualified for automotive applications. The device includes EMI filters and patented circuitry to enable output accuracy with pulse-width modulation (PWM) type input common-mode voltages. The typical input offset voltage is ±200 μV. The AD8417 is offered in 8-lead MSOP and SOIC packages.
- **Applications**
- High-side current sensing in
- Motor controls
- Solenoid controls
- Power management
- Low-side current sensing
- Diagnostic protection
- ### Features and Benefits
- Typical 0.1 μV/°C offset drift
- Maximum ±400 μV voltage offset over full temperature range
- 2.7 V to 5.5 V power supply operating range
- Electromagnetic interference (EMI) filters included
- High common-mode input voltage range
- −2 V to +70 V continuous
- −4 V to +85 V survival
- Initial gain = 60 V/V
- Wide operating temperature range
- AD8417WB: −40°C to +125°C
- AD8417WH: −40°C to +150°C
- Bidirectional operation
- Available in 8-lead SOIC and 8-lead MSOP
- Common-mode rejection ratio (CMRR): 86 dB, dc to 10 kHz
- Qualified for automotive applications
AD8417WHRMZ Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | MSOP-8 |
| Supply Current | 4.1 mA |
| Number of Circuits | 1 Circuit |
| Number of Channels | 1 Channel |
| Common Mode Rejection Ratio | 86 dB |
| Input Capacitance | 2.00 pF |
| Input Impedance | 200 kΩ |
| Input Offset Voltage | 200 µV |
| Input Bias Current | 130 µA |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| 3dB Bandwidth | 250 kHz |
| Minimum CMRR Range | 85dB ~ 95dB |
| Supply Voltage (Max) | 5V ~ 7V |
| Show | |
| Size-Height | 0.85 mm |
| Operating Temperature | -40℃ ~ 150℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Contains Lead |
| Mil-Spec | Yes |
