AD8428ARZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC333942
Category:
Amplifier, Buffer IC
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD8428ARZ Instrument Amplifier, 1, 100V, 50V/ s, 3.5MHz, 4V to 18V, SOIC
Stock Locations:
Availability:
310 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 11.94

Updated at 27/10/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD8428ARZ is a Low Noise Low Gain Drift Instrumentation Amplifier designed to accurately measure tiny, high speed signals. All gain setting resistors for the amplifier are internal to the part and are precisely matched. Care is taken in both the chip pinout and layout. This results in excellent gain drift and quick settling to the final gain value after the part is powered on. The high CMRR prevents unwanted signals from corrupting the signal of interest. The pinout is designed to avoid parasitic capacitance mismatches that can degrade CMRR at high frequencies. This is one of the fastest instrumentation amplifiers available. The circuit architecture is designed for high bandwidth at high gain. The pinout allows access to internal nodes between the first and second stages. This feature can be useful for modifying the frequency response between the two amplification stages, thereby preventing unwanted signals from contaminating the output results.
Fixed gain of 2000
Access to internal nodes provides flexibility
1.5nV/√Hz Input voltage noise
High accuracy DC performance
5ppm/°C Gain drift
0.3µV/°C Offset drift
0.05% Gain accuracy
5000V (HBM) ESD protection
ESD sensitive device, take proper precaution while handling the device.

Show

AD8428ARZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Current	6.5 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Common Mode Rejection Ratio	130 dB
Bandwidth	3.5 MHz
Slew Rate	50.0 V/μs
Gain Bandwidth Product	3.5 MHz
Input Offset Voltage	100 µV
Input Bias Current	200 nA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	3.5 MHz
Minimum CMRR Range	110 dB
Supply Voltage (Max)	30V ~ 50V
	Show
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
