AD8512BRZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC243257
Category:
Operational Amplifier, OP Amp IC
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD8512BRZ Operational Amplifier, Dual, 2 Amplifier, 8MHz, 20V/µs, ± 4.5V to ± 18V, NSOIC, 8Pins
Stock Locations:
Availability:
115 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 9.97

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD8512BRZ is a precision dual JFET Operational Amplifier features low offset voltage, input bias current, input voltage noise and input current noise. It is suitable for high impedance sensor amplification and precise current measurements using shunts. The combination of DC precision, low noise and fast settling time results in superior accuracy in electronic measurement and automated test equipment. Unlike many competitive amplifiers, the AD8512 maintain their fast settling performance even with substantial capacitive loads. Unlike many older JFET amplifiers, the AD8512 do not suffer from output phase reversal when input voltages exceed the maximum common-mode voltage range. Fast slew rate and great stability with capacitive loads make the AD8512 a perfect fit for high-performance filters. Low input bias currents, low offset and low noise result in a wide dynamic range of photodiode amplifier circuits.
No phase reversal
Unity gain stable
500ns to 0.1% Fast settling time
400µV Maximum low offset voltage
8nV/√Hz (typical) at f=1kHz Low noise
0.0005% Low distortion

Show

AD8512BRZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Current	2.2 mA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	86 dB
Bandwidth	8 MHz
Slew Rate	20.0 V/μs
Gain Bandwidth Product	8 MHz
Input Impedance	1.25 TΩ
Input Offset Voltage	0.4 mV
Input Bias Current	0.075 nA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	8 MHz
Minimum CMRR Range	86 dB
	Show
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
