AD9106BCPZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC1536000
Category:
Digital to Analog, DAC IC
Package:
LFCSP-32
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD9106BCPZ Digital to Analogue Converter, Quad, 12Bit, 180MSPS, Single Ended, 1.7V to 3.6V, LFCSP, 32Pins
Stock Locations:
Availability:
305 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 424.17

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD9106BCPZ is a high performance quad Digital-to-analog Converter (DAC) integrating on-chip pattern memory for complex waveform generation with a direct digital synthesizer (DDS). The DDS is a 12-bit output, up to 180MHz master clock sine-wave generator with a 24-bit tuning word allowing 10.8Hz/LSB frequency resolution. SRAM data can includes directly generated stored waveforms, amplitude modulation patterns applied to DDS outputs or DDS frequency tuning words. An internal pattern control state machine allows the user to program the pattern period for DAC as well as the start delay within the pattern period for the signal output on DAC channel. An SPI interface is used to configure the digital waveform generator and load patterns into the SRAM. There are gain adjustment factors and offset adjustments applied to the digital signals on their way into the DAC. It offers exceptional AC and DC performance and supports DAC sampling rates up to 180MSPS.
On-chip DDS
Sleep mode - <5mW at 3.3V
Low power dissipation

Show

AD9106BCPZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	32 Pin
Case/Package	LFCSP-32
Number of Outputs	4 Output
Output Current	4 mA
Number of Channels	4 Channel
Number of Positions	32 Position
Number of Bits	12 Bit
Sample Rate	180 Msps
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	315 mW
Number of DACs	4 DAC
Supply Voltage	1.7V ~ 3.6V
	Show
Size-Length	5.1 mm
Size-Width	5.1 mm
Size-Height	0.75 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	PB free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
