AD9748ACPZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC309874
Category:
Digital to Analog, DAC IC
Package:
LFCSP-32
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD9748ACPZ Digital to Analog Converter, 8Bit, 210MSPS, Differential, Single Ended, 2.7V to 3.6V, LFCSP
Stock Locations:
Availability:
209 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 8.29

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD9748ACPZ is a 8-bit high performance low power CMOS Digital-to-analog Converter specifically optimized for the transmit signal path of communication systems. The AD9748 offers exceptional AC and DC performance while supporting update rates up to 210MSPS. The low power dissipation makes it well suited for many applications. Its power dissipation can be further reduced to 60mW with a slight degradation in performance by lowering the full-scale current output. In addition, a power-down mode reduces the standby power dissipation to approximately 15mW. Segmented current source architecture is combined with a proprietary switching technique to reduce spurious components and enhance dynamic performance. Edge-triggered input latches and a 1.2V temperature compensated band gap reference have been integrated to provide a complete monolithic DAC solution.
High performance member of pin-compatible TxDAC product family
Linearity
Twos complement or straight binary data format
CMOS-compatible digital interface

Show

AD9748ACPZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	32 Pin
Case/Package	LFCSP-32
Number of Outputs	1 Output
Supply Current	33 mA
Number of Channels	1 Channel
Number of Positions	32 Position
Number of Bits	8 Bit
Power Dissipation	145 mW
Sample Rate	210 Msps
Resolution (Bits)	8.0 Bit
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	145 mW
Number of DACs	1 DAC
Supply Voltage	2.7V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	2.7 V
	Show
Size-Length	5 mm
Size-Width	5 mm
Size-Height	0.83 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
