ADCMP562BRQZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC232552
Category:
Comparator, Analog Comparator IC
Package:
QSOP-20
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADCMP562BRQZ Analogue Comparator, Dual, High Speed, 2, 700 ps, 4.75V to 5.25, -4.96V to -5.45V, QSOP, 20Pins
Stock Locations:
Availability:
63 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 8.8

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADCMP562BRQZ is a dual high speed PECL Comparator fabricated on proprietary XFCB process. The device features a 700ps propagation delay with less than 75ps overdrive dispersion. Dispersion, a measure of the difference in propagation delay under differing overdrive conditions, is a particularly important characteristic of comparators. A differential input stage permits consistent propagation delay with a wide variety of signals in the common-mode range from -2 to 3V. Outputs are complementary digital signals that are fully compatible with PECL 10K and 10KH logic families. The outputs provide sufficient drive current to directly drive transmission lines terminated in 50R to VDD to 2V.A latch input, which is included, permits tracking, track-and-hold or sample-and-hold modes of operation. The latch input pins contain internal pull-ups that set the latch in tracking mode when left open.
Differential PECL compatible outputs
Robust input protection
Differential latch control
Internal latch pull-up resistors
85dB Power supply rejection greater than
1.5GHz Equivalent input rise time bandwidth
Programmable hysteresis

Show

ADCMP562BRQZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	QSOP-20
Output Current	30 mA
Supply Current	3.2 mA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Number of Positions	20 Position
Power Dissipation	250 mW
Common Mode Rejection Ratio	80 dB
Input Offset Voltage	2 mV
Input Bias Current	10000 nA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	250 mW
Supply Voltage (Max)	5 V
Supply Voltage (Min)	2.5 V
	Show
Size-Length	8.66 mm
Size-Width	3.91 mm
Size-Height	1.65 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
