ADG1607BRUZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC469504
Category:
Analog Switch Ic, Analog Switch Multiplexer
Package:
TSSOP-28
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADG1607BRUZ 8:1 Analog Multiplexer IC, 8Circuits, 7.5Ω, 3.3V to 16V, TSSOP-28
Stock Locations:
Availability:
229 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 3.34

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADG1607BRUZ is a 8-channel iCMOS® Analogue Multiplexer that switches one of 8 differential inputs to a common differential output, as determined by the 3-bit binary address lines A0, A1 and A2. An EN input on both devices enables or disables the device. When disabled, all channels switch off. When enabled, each channel conducts equally well in both directions and has an input signal range that extends to the supplies. The ultralow on resistance and on-resistance flatness make it ideal solution for data acquisition and gain switching applications where low on resistance and distortion is critical. iCMOS® construction ensures ultralow power dissipation, making the parts ideally suited for portable and battery powered instruments.
1.1R On-resistance flatness
±3.3 to ±8V Dual-supply operation
3.3 to 16V Single-supply operation
No VL supply required
3V Logic compatible inputs
Rail-to-rail operation
Up to 378mA of continuous current per channel
ESD sensitive device, take proper precaution while handling the device.

Show

ADG1607BRUZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	28 Pin
Case/Package	TSSOP-28
Number of Outputs	2 Output
Supply Current	370 µA
Number of Circuits	8 Circuit
Number of Channels	2 Channel
Number of Positions	28 Position
Power Dissipation	1.85 mW
Bandwidth	38 MHz
Number of Inputs	16 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	38 MHz
Supply Voltage	3.3V ~ 16V
	Show
Size-Length	9.8 mm
Size-Width	4.5 mm
Size-Height	1.2 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
