ADG884 - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC983490352
Datasheet:
Datasheet 3D Model
Description:
0.5Ω CMOS Dual 2:1 MUX/SPDT Audio Switch
Stock Locations:
Availability:
240 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Product Details
The ADG884 is a low voltage CMOS device containing two independently selectable single-pole, double-throw (SPDT) switches. This device offers ultralow on resistance of 0.41 Ω over the full temperature range, making the part an ideal solution for applications that require minimal distortion through the switch. The ADG884 also has the capability of carrying large amounts of current, typically 600 mA at 5 V operation.
The ADG884 is available in a 10-ball, 2 mm × 1.5 mm WLCSP package, a 10-lead LFCSP_WD package, and a 10-lead MSOP package. These tiny packages make the ADG884 the ideal solution for space-constrained applications.
When on, each switch conducts equally well in both directions and has an input signal range that extends to the supplies. The ADG884 exhibits break-before-make switching action.
**Product Highlights**
1. Single 1.8 V to 5.5 V operation.
2. High current handling capability (400 mA continuous current).
3. 1.8 V logic compatible.
4. Low THD + N (0.01% typical).
5. Tiny 2 mm × 1.5 mm WLCSP, 3 mm × 3 mm 10-lead LFCSP_WD, and 10-lead MSOP packages.
**
Applications*
* Cellular phones
* PDAs
* MP3 players
* Power routing
* Battery-powered systems
* PCMCIA cards
* Modems
* Audio and video signal routing
* Communications systems
Data Sheet, Rev. C, 6/08
### Features and Benefits
1.8 V to 5.5 V Operation
Ultralow on Resistance:
0.34 Ω Typical
0.38 Ω Max at 5 V Supply
Excellent Audio Performance, Ultralow Distortion:
0.1 Ω Typical
0.15 Ω Max RON Flatness
|
High Current-carrying Capability:
400 mA Continuous
600 mA Peak Current at 5 V Supply
Rail-to-rail Switching Operation
Typical Power Consumption (<0.1 µW)
---|---

Show

ADG884 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
	Show
Product Lifecycle Status	Active
