ADJ56024 - Panasonic
Manufacturer:
Panasonic
ManyChip's Part#:
MC69307200
Category:
Power Relay
Package:
-
Datasheet:
Datasheet 3D Model
Description:
Electromechanical Relay 24VDC 2.304KΩ 16A DPDT (( 29mm 13mm 16.5mm)) THT Power Relay
Stock Locations:
Availability:
1,252 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 5.91

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

FEATURES
1\. Variety of contact arrangements
Wide lineup of 1 Form C, 1 Form A, 1 Form B, 2 Form C, 2 Form A, 2 Form B, 1 Form A 1 Form B.
2\. Latching operation
Latching via a polarized magnetic circuit structure allows remote operation and lower energy consumption
3\. Compact with high capacity
16A (1-pole type) contact rating in a compact 29×13×16.5 mm (L×W×H) size.
4\. Low power consumption
1 coil latching: 150mW
2 coil latching, single side stable: 250mW
5\. High insulation
Both clearance and creepage distance between coil and contact are at 8 mm min.
6\. With operation verification function
A test button (manual lever) type to facilitate circuit checks is also available (1 Form C, 1 Form A, 1 Form B types only).
TYPICAL APPLICATIONS
1\. FA equipment (brake circuits of industrial machine and robots, etc.)
2\. Electric power devices (remote surveillance devices, etc.)
3\. Household appliance networks (Motor control and lighting control, etc.)
4\. Time switches
