ADM00421 - Microchip
Manufacturer:
Microchip
ManyChip's Part#:
MC10843990
Category:
Microprocessor Development Kit
Package:
-
Datasheet:
Datasheet 3D Model
Description:
MCP2210, USB TO SPI, EVALUATION KIT; SVHC: No SVHC (19-Dec-2012) ; RoHS Compliant: Ye
Stock Locations:
Availability:
0 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADM00421 is an evaluation kit for the development and evaluation of MCP2210 device. The MCP2210 Motherboard is designed to work together with the MCP2210 breakout board. The motherboard provides the test points required for measurements. It also contains the 8bit I/O expander, 4 channel and 12bit ADC, 2 kbit EEPROM, temperature sensor SPI slave devices. All devices are SPI slaves and controlled by the MCP2210. Demo software can be used to demonstrate the MCP2210 as a USB to SPI (Master) device and allow I/O control. The MCP2210 device is detected by a Windows based PC host as a Human Interface Device (HID). The accompanying software can be used to exercise the Evaluation Kit"s features. It also provides a reference point for users that want to create custom applications based on the MCP2210. The SPI Terminal Utility is a tool that allows low level data exchange at the SPI bus level.
MCP2210 Breakout Board:
Small plug in board with DIP form factor (2, 10 pin headers spaced at 600mil)
Mini USB connector
Access to the SPI bus and all the GP signals
PICkit Serial Analyzer compatible header
3.3 or 5V jumper selectable VDD and able to supply up to 500mA to the rest of the system
MCP2210 SPI slave Motherboard
Socket insertion for MCP2210 breakout board and easily accessible test point for SPI bus, GP signal
PICkit Serial Analyzer header to access the MCP23S08
Potentiometer allows altering of voltage on the channel 1 ADC input
