Description:
5kV Signal Isolated, ESD Protected, 500kbps, Full/Half Duplex RS-485 Transceiver
Stock Locations:
Availability:
270 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

GENERAL DESCRIPTION
The ADM2484E is an isolated data transceiver with ±15 kV ESD protection suitable for high speed, half- or full-duplex communication on multipoint transmission lines. For half duplex operation, the transmitter outputs and receiver inputs share the same transmission line. Transmitter Output Pin Y links externally to Receiver Input Pin A, and Transmitter Output Pin Z links externally to Receiver Input Pin B.
FEATURES
Isolated, RS-485/RS-422 transceiver, configurable as half- or full-duplex
±15 kV ESD protection on RS-485 input/output pins
500 kbps data rate
Complies with ANSI TIA/EIA RS-485-A-1998 and ISO 8482: 1987(E)
Suitable for 5 V or 3.3 V operation (VDD1)
High common-mode transient immunity: >25 kV/μs
True fail-safe receiver inputs
256 nodes on the bus
Thermal shutdown protection
Safety and regulatory approvals
UL recognition
5000 V rms isolation voltage for 1 minute per UL1577
VDE certificate of conformity
DIN V VDE V 0884-10 (VDE V 0884-10): 2006-12
Reinforced insulation, VIORM = 848 V peak
CSA Component Acceptance Notice #5A
IEC 60950-1: 380 V rms (reinforced)
Operating temperature range: −40°C to +85°C
Wide body, 16-lead SOIC package
APPLICATIONS
Isolated RS-485/RS-422 interfaces
Industrial field networks
INTERBUS
Multipoint data transmission systems
