Description

The ADM2486BRWZ is a Half-duplex iCoupler® Isolated RS-485 Transceiver designed for bidirectional data communication on multipoint bus transmission lines. The device employs the iCoupler® technology to combine a 3-channel isolator, a three-state differential line driver and a differential input receiver. The logic side of the device can be powered with either a 5 or a 3.3V supply, whereas the bus side requires an isolated 5V supply. The ADM2486 driver has an active-high enable feature. The driver differential outputs and the receiver differential inputs are connected internally to form a differential input/output port that imposes minimal loading on the bus when the driver is disabled or when VDD1/VDD2=0V. Also provided is an active-high receiver disable feature that causes the receive output to enter a high impedance state.
Half-duplex, isolated RS-485 transceiver
PROFIBUS® compliant
ANSI EIA/TIA 485-A and ISO 8482:1987 (E) compliant
20Mbps Data rate
High common-mode transient immunity (>25kV/µs)
Isolated DE status output
Receiver has open-circuit, fail-safe design
Thermal shutdown protection
50 Nodes on bus
ESD sensitive device, take proper precaution while handling the device.

Show

ADM2486BRWZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Supply Voltage (DC)	5.00V (max)
Rise/Fall Time	5 ns
Output Current	3 mA
Supply Current	58 mA
Number of Channels	3 Channel
Number of Positions	16 Position
Data Rate	20.0 Mbps
Isolation Voltage	2500 Vrms
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3V, 5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.7 V
	Show
Size-Length	10.5 mm
Size-Width	7.6 mm
Size-Height	2.35 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
