ADUM3152ARSZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC1777138
Category:
Interface Isolator, Digital Isolator
Package:
SSOP-20
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADUM3152ARSZ Digital Isolator, 7Channel, 25ns, 3V, 5.5V, SSOP, 20Pins
Stock Locations:
Availability:
294 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 3.37

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADUM3152ARSZ is a 7-channel, SPIsolator™ Digital Isolator optimized for isolated serial peripheral interfaces (SPIs). Based on the Analog Devices, Inc., iCoupler® chip scale transformer technology, the low propagation delay in the CLK, MO/SI, MI/SO and SS SPI bus signals supports SPI clock rates of up to 17MHz. These channels operate with 14ns propagation delay and 1ns jitter to optimize timing for SPI. It provides three additional independent low data rate isolation channels in three different channel direction combinations. Data in the slow channels is sampled and serialized for a 250kbps data rate with up to 2.5µs of jitter in the low speed channels.
Supports up to 17MHz SPI clock speed
4 High speed, low propagation delay, SPI signal isolation channels
Three 250kbps data channels
>25kV/µs High common-mode transient immunity

Show

ADUM3152ARSZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	SSOP-20
Supply Voltage (DC)	3.00V (min)
Rise/Fall Time	2.5 ns
Number of Channels	7 Channel
Number of Positions	20 Position
Rise Time	2.5 ns
Isolation Voltage	3750 Vrms
Input Current (Min)	8 mA
Maximum Forward Voltage (Max)	5.5 V
Fall Time (Max)	2.5 ns
Fall Time (Max)	2.5 ns
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	Show
Size-Length	7.5 mm
Size-Width	5.6 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
