Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Case/Package | DIP |
Contacts Type | DPDT |
Power Consumption | 100 mW |
Contact Current Rating | 1.00 A |
Coil Voltage | 3 VDC |
Coil Current | 33.3 mA |
Coil Resistance | 90 Ω |
Current Rating (Max) | 1 A |
Coil Voltage (DC) | 3 V |
Input Power (Max) | 30W, 37.5VA |
Operating Temperature (Max) | 85 ℃ |
Operating Temperature (Min) | -40 ℃ |
Show | |
Size-Length | 10.6 mm |
Size-Width | 9 mm |
Size-Height | 9 mm |
Contact Material | Silver Palladium |
Operating Temperature | -40℃ ~ 85℃ |
Product Lifecycle Status | Active |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
HTS Code | 8536490050 |
ECCN Code | EAR99 |
