Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 4 Pin |
Current Rating | 5 A |
Contacts Type | SPST-NO |
Contact Current Rating | 5 A |
Coil Voltage | 24 VDC |
Coil Current | 8.3 mA |
Coil Resistance | 2.88 kΩ |
Current Rating (Max) | 5 A |
Coil Voltage (DC) | 24 V |
Coil Power | 200 mW |
Switching Current (Max) | 5 A |
Operating Temperature (Max) | 85 ℃ |
Operating Temperature (Min) | -40 ℃ |
Show | |
Size-Length | 20.5 mm |
Size-Width | 7.2 mm |
Size-Height | 15.3 mm |
Contact Material | Silver Nickel |
Operating Temperature | -40℃ ~ 85℃ |
Product Lifecycle Status | Active |
Packaging | Tray |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
