- ALF1P12 - Panasonic
-
Manufacturer:Panasonic
-
ManyChip's Part#:MC11689396
-
Category:Power Relay
-
Package:ThroughHole
-
Datasheet:Datasheet 3D Model
-
Description:Power Relay 12VDC 25A SPST-NO (( 30.1mm 15.7mm 23.3mm)) Through Hole
-
Stock Locations:
-
Availability:0 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- General Purpose Relay SPST-NO (1 Form A) 12VDC Coil Through Hole
ALF1P12 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 4 Pin |
| Case/Package | ThroughHole |
| Voltage Rating (AC) | 250 V |
| Current Rating | 20 A |
| Insulation Resistance | 1000 MΩ |
| Contacts Type | SPST-NO |
| Power Consumption | 900 mW |
| Contact Current Rating | 20 A |
| Coil Voltage | 12 VDC |
| Coil Current | 75 mA |
| Coil Resistance | 160 Ω |
| Carry Current | 20.0 A |
| Coil Voltage (DC) | 12 V |
| Coil Power | 900 mW |
| Input Power (Max) | 6.25 KVA |
| Switching Current (Max) | 25 A |
| Operating Temperature (Max) | 60 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Show | |
| Size-Length | 30.1 mm |
| Size-Width | 23.3 mm |
| Size-Height | 23.3 mm |
| Contact Material | Silver Tin Oxide |
| Operating Temperature | -40℃ ~ 60℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| HTS Code | 8536490075 |
| ECCN Code | EAR99 |
