B78108S1103K - Epcos
Manufacturer:
Epcos
ManyChip's Part#:
MC50377094
Category:
Inductor
Package:
Axial
Datasheet:
Datasheet 3D Model
Description:
RF Choke Drum Core 10uH 10% 1MHz 70Q-Factor Ferrite 680mA 490mOhm DCR AXL T/R
Stock Locations:
Availability:
3,919 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.16

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The B78108S1103K is a RF Choke Leaded Inductor, constructed by ferrite drum core, enamel copper wire winding and flame-retardant lacquer coating. Electroplated with nickel and pure tin terminals. Inductance indicated by colour bands to IEC 60062. Suitable for general-purpose application and wave soldering.
Central axial leads
40°C Rated temperature
±5% and ±10% tolerance
Climatic category 55/125/56, IEC 60068-1
Suitable for wave soldering
Base material copper
Electroplated with nickel and pure tin

Show

B78108S1103K Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	2 Pin
Case/Package	Axial
Current Rating	680 mA
Capacitance Tolerance	±10 %
Inductance	10 µH
Self Resonant Frequency	35 MHz
Q-Factor	70.0
Resistance	490 mΩ
Resonant Frequency	35.0 MHz
Shielding	No
Inductance Tolerance	±10 %
Test Frequency	2.52 MHz
DC Resistance (DCR)	≤490 mΩ
Current Rating (DC)	680 mA
Resistance (DC Max)	0.49 Ω
	Show
Size-Length	9.2 mm
Size-Width	4 mm
Size-Diameter	4.00 mm
Lead Length	25.0 mm
Weight	380 mg
Operating Temperature	-55℃ ~ 125℃
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
