B78108S1224J - Epcos
Manufacturer:
Epcos
ManyChip's Part#:
MC56079496
Category:
Inductor
Package:
Axial
Datasheet:
Datasheet 3D Model
Description:
Ind RF Choke Bobbin Core 220uH 5% 100kHz 70Q-Factor Ferrite 250mA AXL T/R
Stock Locations:
Availability:
2,006 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.27

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The EPCOS B78108S series are axial leaded bobbin core (BC) RF chokes for general purpose applications. These chokes are made up of large ferrite drum core with enamel copper wire winding and flame retardant lacquer coating. The B78108S series RF chokes are suitable for RF blocking, filtering, decoupling, interference suppression, antenna systems and energy saving lamps.
Selectable inductance value from 1µH to 4700µH
Rated current ranges from 55mA to 1.2A
±5% and ±10% tolerance
Climatic category 55/125/56, IEC 60068-1
Suitable for wave soldering
Base material copper
Electroplated with nickel and pure tin

Show

B78108S1224J Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	2 Pin
Case/Package	Axial
Current Rating	250 mA
Capacitance Tolerance	±5 %
Inductance	220 µH
Self Resonant Frequency	3.7 MHz
Q-Factor	70.0
Resistance	3.30 Ω
Resonant Frequency	3.70 MHz
Shielding	No
Inductance Tolerance	±5 %
Test Frequency	796 kHz
DC Resistance (DCR)	≤3.3 Ω
Current Rating (DC)	250 mA
Resistance (DC Max)	3.3 Ω
	Show
Size-Length	9.2 mm
Size-Width	4 mm
Size-Diameter	4.00 mm
Lead Length	25.0 mm
Weight	380 mg
Operating Temperature	-55℃ ~ 125℃
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
