BAS86 - NXP
Manufacturer:
NXP
ManyChip's Part#:
MC114819153
Category:
Schottky Diode
Package:
SOD-80
Datasheet:
Datasheet 3D Model
Description:
NXP BAS86 Small Signal Schottky Diode, Single, 50V, 200mA, 900mV, 500mA, 125℃
Stock Locations:
Availability:
3,593 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.21

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The BAS86 is a planar Schottky Barrier Diode with an integrated guard ring for stress protection, encapsulated in a small hermetically sealed SOD80C glass surface-mounted device (SMD) package with tin-plated metal discs at each end. It is suitable for automatic placement and as such it can withstand immersion soldering. It is used for ultra high-speed switching, voltage clamping, protection circuits and blocking diodes.
Low forward voltage
High breakdown voltage

Show

BAS86 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package	SOD-80
Number of Positions	2 Position
Forward Voltage	0.9 V
Reverse recovery time	4 ns
Forward Current	200 mA
Max Forward Surge Current (Ifsm)	500 mA
Maximum Forward Voltage (Max)	900 mV
Forward Current (Max)	200 mA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-65 ℃
	Show
Size-Length	3.7 mm
Size-Width	1.6 mm
Size-Height	1.6 mm
Product Lifecycle Status	Unknown
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
