Description
- DESCRIPTION
- Planar Schottky barrier diodes encapsulated in a SOT323 very small SMD plastic package. Single diodes and double diodes with different pinning are available.
- FEATURES
- • Very low forward voltage
- • Very low reverse current
- • Guard ring protected
- • Very small SMD plastic package.
- APPLICATIONS
- • Ultra high-speed switching
- • Voltage clamping
- • Protection circuits
- • Blocking diodes
- • Low power consumption applications (e.g. hand-held applications).
BAT854CW Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 3 Pin |
| Case/Package | SOT-323-3 |
| Maximum Forward Voltage (Max) | 550mV @100mA |
| Forward Current (Max) | 200 mA |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -65 ℃ |
| Junction Temperature | 150℃ (Max) |
| Show | |
| Size-Length | 2.2 mm |
| Size-Width | 1.35 mm |
| Size-Height | 1 mm |
| Product Lifecycle Status | Unknown |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
