BQ34Z100EVM - TI
Manufacturer:
TI
ManyChip's Part#:
MC2342010
Category:
Microprocessor Development Kit
Datasheet:
Datasheet 3D Model
Description:
Bq34z100EVM 1s to 16s Impedance Track Fuel Gauge Battery Evaluation Module | Gas Gauge Battery
Stock Locations:
Availability:
30 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 90.39

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The BQ34Z100EVM is a is a complete evaluation system for the bq34z100 wide range fuel gauge for lithium ion chemistries when combined with an EV2300 USB adapter and Windows based PC software. The circuit module includes bq34z100 integrated circuit (IC) and all other components necessary to monitor and predict capacity in 1 or more series cell Li ion, Li polymer, or LiFePO4 battery packs. The circuit module connects directly across the battery. With the EV2300 interface adapter and software, it is possible to read the bq34z100 data registers, program the chip for different pack configurations, log cycling data for further evaluation, and evaluate the overall functionality of the bq34z100 solution under different charge and discharge conditions.
Populated circuit module for quick setup
Supports Li ion and LiFePO4 chemistries
Capacity estimation using patented impedance track technology for batteries from 3V to 65V
Supports battery capacities above 65Ahr
Supports charge and discharge currents above 32A
Supports two wire I2C and HDQ single wire communication
SHA-1/HMAC authentication
One or four LED direct display control
Five LED and higher display through port expander
Link to software allowing data logging for system analysis
Applying a voltage higher than 5 V when jumpers are configured for 1S operation will very likely damage the IC.
