Description

The BTS721L1 is a 4-output high-side vertical Power FET Switch with charge pump, ground referenced CMOS compatible input and diagnostic feedback. It is monolithically integrated in smart SIPMOS® technology, providing embedded protective functions, under-voltage and overvoltage shutdown with auto-restart and hysteresis.
Overload protection
Current limitation
Short-circuit protection
Thermal shutdown
Overvoltage protection
Fast demagnetization of inductive loads
Reverse battery protection
Open drain diagnostic output
Open load detection in ON-state
Loss of ground and loss of VBB protection
Electrostatic discharge (ESD) protection
High voltage capability
Benchmark energy robustness
ESD sensitive device, take proper precaution while handling the device.

Show

BTS721L1XUMA1 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	SOIC-20
Number of Outputs	4 Output
Input Voltage (DC)	16.0 V
Output Current	2.5 A
Supply Current	8 mA
Number of Positions	20 Position
Power Dissipation	3.7 W
Output Current (Min)	2.5 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	3700 mW
Input Voltage	16 V
	Show
Operating Temperature	-40℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
