CC2420RTC - TI
Manufacturer:
TI
ManyChip's Part#:
MC102408400
Category:
RF Module
Package:
VFQFN-48
Datasheet:
Datasheet 3D Model
Description:
Single-Chip 2.4GHz IEEE 802.15.4 Compliant and ZigBee Ready RF Transceiver 48-VQFN -40℃ to 85℃
Stock Locations:
Availability:
369 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 6.15

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

* True single-chip 2.4 GHz IEEE 802.15.4 compliant RF transceiver with baseband modem and MAC support * DSSS baseband modem with 2 MChips/s and 250 kbps effective data rate. * Suitable for both RFD and FFD operation * Low current consumption (RX: 18.8 mA, TX: 17.4 mA) * Low supply voltage (2.1 – 3.6 V) with integrated voltage regulator * Low supply voltage (1.6 – 2.0 V) with external voltage regulator * Programmable output power * No external RF switch / filter needed * I/Q low-IF receiver * I/Q direct upconversion transmitter * Very few external components * 128(RX) + 128(TX) byte data buffering * Digital RSSI / LQI support * Hardware MAC encryption (AES-128) * Battery monitor * QLP-48 package, 7×7 mm * Complies with ETSI EN 300 328, EN 300 440 class 2, FCC CFR-47 part 15 and ARIB STD-T66 * Powerful and flexible development tools available

Show

CC2420RTC Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	48 Pin
Case/Package	VFQFN-48
Frequency	2.4 GHz
Supply Voltage (DC)	2.10V (min)
Supply Current	17.4 mA
Data Rate	250 kbps
Output Power	-24dBm ~ 0dBm
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	2.1V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	2.1 V
	Show
Size-Length	7.00 mm
Size-Width	7.00 mm
Size-Height	0.9 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	5A002
